Extra Slimline Shock (Inertia) - White/Brown

HKC's exceptional PIR's are available in Dual and Quad versions. 15m range.
ABS housing 15m detection Built-in EOL resistors Can operate via 3-wire ID-bus 10 ID PIR's per ID zone Adjustable sensitivity Temperature compensation For use on all HKC wired and hybrid systems as well and many other panels

Building on our long tradition of manufacturing stable and robust inertia sensors and magnetic contacts, HKC is pleased to introduce its Extra Slim range of wired devices.The sensors are designed to fit onto the smallest of door and window frames without any compromise.
Weight: 30g (main module), 20g (magnet) Size: 91mm x 24mm x 21mm (main module) Size: 91mm x 22mm x 12mm (magnet) BS 8243 & PD6662 EN 50136-2-6 & EN 50131-2-8 (Grade 2) Environmental Class II

Over two decades of experience are found in our ID wired inertia sensor. This device is for use with all wired HKC panels including our Hybrid panels the SW 1070 and SW 20140
Detects vibrations on doors, windows, etc. White or brown ABS housing Polycarbonate sensor head Gold-plated contacts Available with combined reed switch option (magnetic contact) 10 ID sensors per ID zone LED status indicator Terminals for sensor contact and tamper inputs. ID Zone Module comes without sensor head and may be used as a zone input for other detection technologies

Over two decades of experience are found in our ID wired inertia sensor. This device is for use with all wired HKC panels including our Hybrid panels the SW 1070 and SW 20140.
Detects vibrations on doors, windows, etc. White or brown ABS housing Polycarbonate sensor head Gold-plated contacts Available with combined reed switch option (magnetic contact) 10 ID sensors per ID zone LED status indicator Terminals for sensor contact and tamper inputs. ID Zone Module comes without sensor head and may be used as a zone input for other detection technologies

Input unit that resides on the Point ID bus.
Up to 10 modules per ID bus Comes in ABS housing 1.5A

Input unit that resides on the Point ID bus.
Up to 10 modules per ID bus Comes in ABS housing 1.5A
