External Protection

While HKC’s Intruder systems protect the interior of the property, the addition of Optex External Sensors means you can protect the entire site

Talk to an Expert

Outdoor intrusion detection – protecting your whole property

While HKC’s Intruder systems protect the interior of the property, the addition of Optex’s External Sensors means you can protect the entire site – from the perimeter, to the approach and the external boundaries.

With more than 45 years of sensing expertise, Optex have developed a complete range of sensors for every situation - from residential properties to large or commercial premises.  We've created a complete solution that allows Optex sensors to be integrated fully into your HKC intruder security system.  Optex sensors are designed and tested to perform under all kinds of weather conditions to give your customers ultimate peace of mind.



RF-Optex Module for External PIRs

The RF-Optex module has been designed specifically to integrate Optex sensors within an HKC alarm system installation

Once connected, the RF-Optex module relays the Alarm/Tamper signals wirelessly to the HKC SW-10270 Control Panel using SecureWave technology and can be controlled and monitored via the SecureComm app.

Featured Product: WXS-RAM

WXS-RAM Wireless outdoor 180-degree PIR with antimasking

The Optex WXS sensor, part of the WX Shield series, is designed for outdoor intrusion detection. It features a 180° detection area and can be mounted at various heights, making it versatile for different environments.

Dual Technology: Combines Passive Infrared (PIR) and Microwave sensors for enhanced reliability.

Anti-Masking: Prevents tampering by detecting attempts to cover or block the sensor.

Flexible Mounting: Can be installed at low (0.8 - 1.2m) or high (2m) heights.

Individual Detection Areas: Allows for separate sensitivity settings and alarm outputs for the left and right detection zones.

Environmental Stability: Designed to minimize false alarms caused by light disturbances or radio frequency interference.

This sensor is ideal for protecting residential and commercial premises, including approaches, gardens, and flat roofs.

Featured Product: AX-100/200TFR

AX-100/200TFR Outdoor wireless infrared beam,
This sensor is particularly useful for securing residential and commercial properties without the need for extensive wiring, placed to protect perimeter entrances or driveways.

Wireless Battery-powered outdoor active infrared beam is  a convenient low cost alternative to hard-wired external sensors, helping provide a new layer of external perimeter protection to your HKC intruder security system.

It’s stylish design is quick and easy to install, wireless configuration allows for flexible location options, is compatible with HKC’s RF Optex Module·

Weather Resistance: It is designed to perform reliably in various weather conditions, with features like rain, dust, and insect protection.

Tamper Protection: Includes triple tamper functions to prevent tampering.

Versatile Applications: Suitable for protecting driveways, open areas, small perimeters, and building approaches.

Compatibility

Compatibility

We have thoroughly tested a range of Optex products. The following are compatible with HKC systems:

SeriesModelType
VXS seriesRAM, RDAMOutdoor PIR sensors
VXI seriesR, RAM, RDAMOutdoor Dual PIR sensors
BXS seriesR, RAMOutdoor Quad PIR sensors
WXI seriesR, RAMHigh performance outdoor PIR sensors
WXS seriesRAM, RDAMHigh performance dual-tech outdoor sensors
QXI seriesR, RDTHigh or low mount outdoor PIR and dual-tech sensors
HX series40 RAM, 80 NRAMHigh-mount outdoor detectors
AX beams100 TFR, 200 TFROutdoor photoelectric beam detectors
SL 350QFR QNRHigh performance outdoor photoelectric beam detectors
FTNR, RAMCompact outdoor PIR sensors
